Alloyworks 4 Rows All-aluminum Radiator For 1967-1972 Chevy Blazer Truck C10 C20 C30 K10 K20 Suburban L6 V8 GMC 4.0L 4.8L 5.0L 5.7L 6.6L 19-1/4" Height x 33-7/8" Width

Alloyworks 4 Rows All-aluminum Radiator For 1967-1972 Chevy Blazer Truck C10 C20 C30 K10 K20 Suburban L6 V8 GMC 4.0L 4.8L 5.0L 5.7L 6.6L 19-1/4" Height x 33-7/8" Width

RAD-CHEV-AL-45
$259.00
$279.00
Save 7%
Quantity
Important Notice

This radiator can be easily purchased incorrectly, please verify the size of your vehicle before placing your order.
Please check if this fits your vehicle before purchasing
USA Local Warehouses
1 Year Warranty
60 Days Easy Return
Please check if this fits your vehicle before purchasing
Radiator Size

Core Size: 17" H x 28-1/4" W x 2 4/9''Thick

Overall Size: 19-1/4" H x 33-7/8"W

Upper inlet: 1-1/2" located

Lower outlet: 1-3/4" located

Please check the size carefully before purchase.

Row: 4 Row Core

Material: AA5052 Aluminum

Radiator Cap: included

Core and Tank: AA5052 Aluminum

Includes CNC machined filler neck and cap

OEM Style Brass Petcock Drain.

1. This radiator is constructed from AA5052 aircraft aluminum, a material with magnesium as its major alloying element. This choice imparts greater strength and superior corrosion resistance, even in saltwater environments.

2. The core of This radiator boasts a higher density, with cooling rows spaced just 3/8" apart. This design provides 25% more rows within the core compared to other aluminum radiators commonly available on eBay.

3. The C10 radiator features 14-16 cooling fins per inch, adding about 1,500 more fins compared to other aluminum Chevy radiators. By adjusting tube spacing to 3/8" intervals and increasing fin count, the AA5052 aluminum core becomes denser, significantly boosting heat dissipation. This high-efficiency design delivers 30%-45% better cooling performance than OEM radiators, making it an ideal upgrade for enhanced temperature control.

Radiator Features

ISO/IATF16949 Certified: Full Aluminum Radiator for Superior Cooling and Perfect Fit

The core of this vehicle radiators is welded in a vacuum brazing furnace, with no epoxy. The Radiator is 100% welded by TIG. Stronger and higher Capacity for Coolant than OEM units, Made of High-Quality AA5052 Aircraft Grade Aluminum Construction.

This aircraft-grade aluminum radiator is engineered for maximum cooling efficiency, reducing the risk of engine failure. Made from lightweight, high-heat transferring aluminum with a tube and fin design, it significantly increases surface area for better heat dissipation. Compared to stock car radiators, it offers 35%-45% greater efficiency and a higher coolant capacity, making aluminum radiators ideal for enhanced performance and resistance to temperature surges, especially in racing applications.

Package Includes

1 X 4 Row AA5052 Aluminum Radiator

1 X CNC Machined Radiator Cap

Advanced Production Process

Carefully crafted to meet exceptional OE standards for a precise fit, using Aircraft AA5052 grade aluminum.

Leading-edge Technology

Brazed core technology for at least 30%-45% more efficient in heat transferring than stock ones.

Why AlloyWorks

Established in 2006, AlloyWorks has been offering top notch quality car parts to ensure the best satisfaction of customers.

Advanced Production Process

Carefully crafted to meet exceptional OE standards for a precise fit, using Aircraft AA5052 grade aluminum.

Leading-edge Technology

Brazed core technology for at least 30%-45% more efficient in heat transferring than stock ones.

Why AlloyWorks

Established in 2006, AlloyWorks has been offering top notch quality car parts to ensure the best satisfaction of customers.
