Product Details：
Weight ： 17.6 lbs
Height : 6.5 in
Width : 6.5 in
Length : 9.6 in
Wheel Pilot Diameter : 2.49 in. / 63.3 mm
Wheel Lug Quantity : 5
Knuckle Bolt Hole Size : M12*1.5
Knuckle Bolt Circle Diameter : 4.72 in. / 120 mm
Inside Spline Quantity : 38
Hub Pilot Diameter : 3.62 in. / 92 mm
Flange Shape: Rectangular
Flange Offset : 1.69 in. / 43 mm
Flange Diameter : 5.74 in. / 145.7 mm
Flange Bolt Hole Quantity : 4
Brake Pilot Diameter : 2.68 in. / 68 mm
Bolt Thread Pitch: 1/2'-20UNF
Bolt Size : 1/2*20UNF
Bolt Pattern : 5 x 4.5 in.
Bolt Circle Diameter : 4.5 in. / 114.3 mm
Performance:
Rolling technology.
Light weight miniaturization.
Low friction moment.
100% Factory tested.
Manufactured to meet or exceed expectations for performance and fit.
High Performance Seal Ring Design Ensures a Clean, Long Lasting HUB bearing.
