Aluminum 4 Row Radiator For 1975-1978 76 77 Ford Mustang II 302Cu CC514 5L V8

536-51135DZ

$198.01 20 % $247.51
17 sold
Qty
Product description
Product description

Application:
For 1975 76 77 1978 Ford Mustang II 5.0L(302ci) V8 Engine

Click here to view all compatible vehicles


Configuration:
High Performance Racing Spec.
4-Row of tubes Core Racing Design
Core Material: All Aluminum
Tank Material: T-5057 Aircraft Grade Aluminum
Surface Finish: Aircraft Grade Raw Aluminum
Includes CNC machined filler neck and cap
Overall Height: 22 X Width: 25 1/2
Core Height: 16 1/2 X Width: 23
Inlet Diameter: 1 1/2"Passenger Location
Outlet Diameter: 1 1/2"Driver Location
Transmission Oil Cooler Fitting Type: 1/8-27NPT
Internal Transmission Oil Cooler: Yes
OEM Style Brass Petcock Drain.
Please Check the Size Before You Buy!


Description:
The core of the radiator is welded in vacuum brazing furnace, no epoxy.The Radiator are 100% welded by TIG.Stronger & Higher Capacity for Coolant than OEM units,Made of High Quality Full T-5057 Aircraft Grade Raw Aluminum Construction
Full Raw Aluminum radiator is designed to provide maximum cooling efficiency to prevent premature engine failure. Its light-weight, and high-heat transferring aluminum features a tube and fin design that, dramatically increases surface area that enables the heat to dissipate more efficiently. This High Quality Raw Aluminum Radiator is at least 35% to 45% more efficient than stock ones. Most importantly, it has a much higher capacity for coolant than stock ones, which means that your cooling system will be more efficient and will be more resistant to temperature surges in racing applications.
