Fitments:
NOTE :THIS RADIATOR WITH OIL COOLER
Fits Case Construction & Industrial(s) 430CK, 480B, 480CK, 530CK, 580B (with Shuttle Transmission), 580BCK (with Hydrostatic Transmission), 580CK (s/n 8685800-earlier)
Replaces Case OEM nos: A39344, A35604
CASE/IH TRACTORS 580BCK A39344, A35604 Hydro Gas/Diesel
CASE/IH TRACTORS 530CK A39344, A35604 Gas & Diesel w/Std. Transmission
CASE/IH TRACTORS 580B A39344, A35604 B Series w/Mech. Shuttle, Hydro Gas/Diesel
CASE/IH TRACTORS 580CK A39344, A35604 159 Gas & Diesel w/mechanical shuttle transmission
CASE/IH TRACTORS 480CK A39344, A35604 B Series Backhoe/Loader
CASE/IH TRACTORS 580CK A39344,A35604 SN 8685801 & Before; (Std.) w/oil cooler 9521
CASE/IH TRACTORS 430CK A39344, A35604
CASE/IH TRACTORS 480B A39344, A35604 Gas & Diesel
Radiator Size:
Overall Diameter: Height 26" X Width 19"
Core Diameter: Height 17-5/8" X Width 18-5/16" x 2''Thick
Inlet/Outlet Diameter: 2"/1-3/4"
Depth: 2-1/8"
Fins Per Inch: 8
Fill Neck Height: 1-3/8"
Specifications:
High-Performance Racing Spec.
3-Row of tubes Core Racing Design
Core Material: All Aluminum
Tank Material: AA5052 Aircraft Grade Aluminum
Surface Finish: Aircraft Grade Raw Aluminum
Includes CNC machined filler neck and cap
Radiator Oil Cooler: Include
OEM Style Brass Petcock Drain.
Please Check the Size Before You Buy!
Features:
The core of the radiator is welded in a vacuum brazing furnace, free of epoxy. This Case radiator is 100% TIG welded for maximum durability, offering a stronger and higher coolant capacity than OEM units.
Made of high-quality full AA5052 aircraft-grade raw aluminum, this radiator is designed to provide maximum cooling efficiency and prevent premature engine failure. Its lightweight, high-heat transferring aluminum features a tube and fin design that dramatically increases surface area, enabling more efficient heat dissipation.
This high-quality raw aluminum radiator is at least 35% to 45% more efficient than stock models. Most importantly, it has a significantly higher coolant capacity, making your cooling system more effective and resilient against temperature surges, especially in racing applications.
