Package Including:
1 x Oil Catch Tank
2 x Filters
1 x Drain Tap
All accessories as photo shown
Specs:
Condition: New
Material: Aluminium
Color: Black
Depth: 110 mm
Width: 110 mm
Height: 160 mm (310 mm with filter and drain)
Volume: 2.0 L
Type: Recirculating or Breathe to atmosphere
Number of inlet ports: 2
Inlet port: 12AN ORB female
Inlet port fitting included: None included
Return/breather port: 12AN JIC male
Return port fitting included: None included
Drain port: 10AN ORB female
Drain port fitting included: Tap
Construction: Fabricated
Baffled: Yes
Fluid level indicator: No
Baffled tank with 2 x 12AN female ports
2 x 12AN top fitting for return lines or filters (included)
Filter has a cleanable stainless steel gauze (70 mm H 70 mm Dia)
10AN drain can be used as a return line or drain using the included tap (tap can also be fitted with a return line using the 1/8 NPT thread cut into the bung)
100% Brand New
Build With Stainless Steel Filter Inside For Better Performance.
This Oil Catch Tank Will Collect Oil And Moisture Blow By Gases From Pcv Valve Or Engine Valve Cover Ports Going To Intake System
With This Oil Catch Can You Keep Your Engine Clean Under Hard Driving Conditions
Allowing “cleaner” Gases To Be Passed Back Into The Intake.
Keeping The Engine Intake,valves And Pistons Clean Will Not Loss Power In The Future.
Made Of High Quality Aluminum Sheet, Tig Welded Construction
Drainer At The Bottom For Easy Draining
Fitting Bracket Welded On To The Tank
Perfect For Turbo & Non Turbo Engines
Please Note : No Installation Instruction Included, Professional Installation Recommended
